Products

Position:Home>Products>Lithium polymer battery

1000-4999mAh lipo battery

Click:2454 2021-10-26

Application and feature:

1) Medium capacity Lithium Ion Polymer cells are often used to power larger portable consumer devices and industrial applications requiring higher power levels and longer life. Cells can be configured for higher discharge current levels if required. Cells can be combined in series to increase voltage and parallel to increase capacity. Protection Circuit Modules (PCM) are available to ensure safe battery operation. These are specified to application discharge current levels. NTC thermal fuses and gas gauging can be added if required. Connection method can be tabs, wires or a specified connector. Battery management electronics are available.
2) Width and length are fixed for each cell size but thickness is variable,which can increase or decrease cell capacity.
3) Adding a Protection Circuit Module(PCM) will add approx 1.5-2.0(mm) to the cell length

Below is our model list for your choosing (if you can’t find the model which you want, we can customize a battery based on your required size)

enquire

Description

Type	Rated Capacity (mAh)	Nominal Voltage (v)	Thickness (mm)	Width (mm)	Length (mm)	Weight (g)
403090	1000	3.7	4	30	90
603448	1000	3.7	6	34	48
603450	1000	3.7	6	34	50.5
503559	1000	3.7	5	35	59
383875	1000	3.7	3.8	38	75
554050	1000	3.7	5.5	40.5	51
324495	1000	3.7	3.2	44	95
534745	1000	3.7	5.3	47	45
405058	1000	3.7	4	50	58
405068	1000	3.7	4	50	68
425070	1000	3.7	4.2	50	70
405078	1000	3.7	4	50	78
406080	1000	3.7	4	60	82
504650	1050	3.7	5	46	50
503272	1100	3.7	5	32	72
503272	1100	3.7	4.2	35	86
603553	1100	3.7	6	35.5	54
454254	1100	3.7	4.5	42	54
414954	1100	3.7	4.1	49	54
505050	1100	3.7	5	50	50
405060	1100	3.7	4	50	60
305585	1100	3.7	3	55	85
355585	1100	3.7	3.5	55	85
603262	1120	3.7	6	32	62
533759	1150	3.7	5.3	37	59
494650	1150	3.7	4.9	46	50.5
534250	1170	3.7	5.3	42	51
503759	1200	3.7	5	37	59
504254	1200	3.7	5.3	42.5	54.5
474362	1200	3.7	4.7	43	62
455058	1200	3.7	4.5	50	58
385068	1200	3.7	3.8	50	70
563759	1250	3.7	5.6	37.5	60
553759	1250	3.7	5.9	37.5	60.5
444765	1250	3.7	4.4	47.5	65
603096	1300	3.7	6	30	96
505053	1300	3.7	5	50	53
505058	1300	3.7	5	50	58
365078	1350	3.7	3.6	50	80
523090	1400	3.7	5.2	30.5	90.5
604060	1400	3.7	6	40	60
454768	1400	3.7	4.5	47	68
554858	1400	3.7	5.5	48	58
325585	1400	3.7	3.2	55	85
405062	1420	3.7	4	50	62
65050	1450	3.7	6	50	50
605050	1450	3.7	6	50	51.5
515058	1450	3.7	5.1	50	58
555058	1450	3.7	5.5	50	58
503396	1500	3.7	5	33	96
543864	1500	3.7	6.2	38	65
554080	1500	3.7	5.5	40	80
505068	1500	3.7	5	50	68
455078	1500	3.7	4.5	50	78
416066	1500	3.7	4.1	60.5	67
454080	1550	3.7	4.7	40	81
5532100	1600	3.7	5.5	32	100
603480	1600	3.7	6	34	80
503497	1600	3.7	5	34	97
554362	1600	3.7	5.8	43	62
554765	1600	3.7	5.5	47.5	65
564863	1600	3.7	5.6	48	63
605058	1600	3.7	6	50	58
505068	1600	3.7	5	50	69.5
355291	1600	3.7	3.5	52	91
425375	1600	3.7	4.2	53	75
465575	1600	3.7	4.6	57	75
406066	1600	3.7	4	60	66
4930108	1650	3.7	4.9	30	108
414973	1650	3.7	4.2	49.5	73
495859	1650	3.7	4.9	58	59
604362	1700	3.7	6	43	62
454864	1700	3.7	5.2	48	64
505078	1700	3.7	5	50	78
6032100	1800	3.7	6	32	100
5040100	1800	3.7	5	40	100
5040100	1800	3.7	5	42	100
564768	1800	3.7	5.6	47	68
555068	1800	3.7	5.5	50	68
3850100	1800	3.7	3.8	50	100
405291	1800	3.7	4	52	91
3553100	1800	3.7	3.5	53	100
356096	1800	3.7	3.5	60	96
456268	1800	3.7	4.5	62	68
386295	1800	3.7	3.8	62	96
356696	1800	3.7	3.5	66	96
525464	1900	3.7	5.2	54	64
5534120	2000	3.7	5.5	34	120
535130	2000	3.7	5	35	130
555078	2000	3.7	5.5	50	78
505280	2000	3.7	5	52	80
405396	2000	3.7	4	53	96
505572	2000	3.7	5	55	72
506066	2000	3.7	5.2	60	67
406096	2000	3.7	4	60	97
506268	2000	3.7	5	62	68
406295	2000	3.7	4	62	96
3468100	2000	3.7	3.4	68	100
505467	2050	3.7	5	54.5	67
430160	2100	3.7	4	30	160
474596	2100	3.7	4.8	45	96
445135	2100	3.7	4	45	135
425978	2100	3.7	4.25	58.5	77.5
506066	2100	3.7	5	60	66
367290	2100	3.7	3.6	72	90
5423180	2200	3.7	5.4	23	180
6030145	2200	3.7	6	30	145
563497	2200	3.7	5.6	34.5	97
5535130	2200	3.7	5.5	35	130
5535135	2200	3.7	5.5	35	136.5
554985	2200	3.7	5.5	49	86
465585	2200	3.7	5.3	55	85
4555110	2200	3.7	4.5	55.5	112.5
3568100	2200	3.7	3.5	68.5	100.5
467085	2200	3.7	4.6	70	85
3568100	2200	3.7	2 Series
487070	2250	3.7	4.8	70	70
55396	2300	3.7	5	53	96
505682	2300	3.7	5	56	83
426379	2300	3.7	4.25	62.5	80
456383	2300	3.7	4.5	63	83
6045135	2400	3.7	6	45	137
4750100	2400	3.7	4.7	50	100
554596	2400	3.7	5.5	50	100
6035140	2500	3.7	6	35	140
535146	2500	3.7	5	35	146
4835158	2500	3.7	4.8	35	158
545135	2500	3.7	5	45	135
555396	2500	3.7	5.5	53	96
3860120	2500	3.7	3.6	60	120
557070	2500	3.7	5.5	70	70
437174	2500	3.7	4.3	71.5	74.5
476096	2550	3.7	4.7	60	96
483096	2600	3.7	4.8	30	96
604596	2600	3.7	6	45	96
456096	2600	3.7	4.5	60	96
456295	2600	3.7	4.5	62	95
506581	2600	3.7	5	65	83
3868100	2600	3.7	3.8	68	101
516184	2700	3.7	5.1	61	84
5545135	2800	3.7	5.5	45	135
5248125	2800	3.7	5.2	48	125
456696	2800	3.7	5	60	97
526186	2800	3.7	5.4	61.5	86
527085	2800	3.7	5.2	70	85
527076	2840	3.7	5.2	71	77
5845102	2900	3.7	5.8	45	102
605490	2900	3.7	6	54	90
4568100	2900	3.7	4.5	68	100
5842145	3000	3.7	5.8	42	145.5
4845130	3000	3.7	4.8	45	130
4848135	3000	3.7	4.8	48	135
6050100	3000	3.7	6.2	50.5	101
605585	3000	3.7	6	55	85
605585	3000	3.7	6	55.5	86.5
4058110	3000	3.7	4.2	58	115
586090	3000	3.7	5.8	60	90
556096	3000	3.7	5.5	60	96
3260170	3000	3.7	3.2	60	170
5565125	3000	3.7	5.5	65	126
4262102	3050	3.7	4.2	62	102
5553135	3100	3.7	5.5	53	135
4764105	3100	3.7	4.7	64	105
5839113	3200	3.7	5.8	39	113
5839113	3200	3.7	5.8	39	113
5548112	3200	3.7	5.4	49	118
553135	3200	3.7	5	53	136
4265125	3200	3.7	4.2	65	126
568100	3200	3.7	5	68	100
4278105	3200	3.7	4.2	78	105
4660120	3250	3.7	4.4	60	120
4660120	3250	3.7	4.6	60	120
6052103	3300	3.7	6	52	103
5255110	3300	3.7	5.2	55	111
4272113	3300	3.7	4.2	72	113
507295	3300	3.7	5.4	73	96
4010196	3400	3.7	4	10	196
4743178	3500	3.7	4.7	43	178
548135	3500	3.7	5	48	135
5558118	3500	3.7	5.5	58	118
566295	3500	3.7	5.6	62	95
5063113	3500	3.7	5	63	114
4565125	3500	3.7	4.3	65	125
5568100	3500	3.7	5.5	68	100
6032200	3600	3.7	6	32	200
5550140	3600	3.7	5.5	50	140
5065125	3600	3.7	5	65	125
36102102	3600	3.7	3.6	102	102
5565103	3700	3.7	5.5	65.5	103.5
4865143	3800	3.7	4.8	65	141
508792	3900	3.7	5	87	92
548792	3900	3.7	5.4	87	92
548165	4000	3.7	5	48	165
560136	4000	3.7	5	60	136
6063113	4000	3.7	6	63	113
4565145	4000	3.7	4.5	65	145
6032100	1600	3.7
469153	4000	3.7	4	69	153
4273135	4000	3.7	4.2	73	135
568080	4000	3.7	5.6	80	80
558792	4000	3.7	5.5	87	92
2880200	4300	3.7	2.8	80	200
565143	4400	3.7	5	65	143
565143	4400	3.7	5	65	143
5840198	4500	3.7	5.8	40	198
4869120	4500	3.7	4.8	69	121
582120	4500	3.7	5	82	120
6053140	4550	3.7	6	53	140
